#include <rc_abstract_portal.h>
Definition at line 340 of file rc_abstract_portal.h.
Public Types | |
| typedef PORT | port_type |
| typedef port_traits::if_type | if_type |
| typedef rc_accessor < if_type > | accessor_type |
Public Member Functions | |
| void | bind_static (port_type &port_) |
| bind the portal to the given static port | |
| void | bind_static (if_type &channel_) |
| bind the portal to a given static channel | |
| void | bind_dynamic (port_type &port_) |
| create a new accessor and bind it to the given dynamic port | |
| void | dynamic_port (port_type &port_) |
| allows dynamic port binding (alias for bind_dynamic()) | |
| virtual void | unused () |
| bind static_port to rc_fallback_interface<IF> | |
| virtual bool | is_unused () const |
| port_type & | get_static_port () |
| returns the static port | |
Public Attributes | |
| port_type | static_port |
| the port for the static interface | |
Protected Member Functions | |
| rc_abstract_portal () | |
| constructors | |
| rc_abstract_portal (const sc_module_name &module_name) | |
| virtual void | bind_static_object (const rc_object_handle &obj_to_bind) |
| Instructs the switch to bind itself to the given static object. | |
| virtual void | bind_dynamic_object (const rc_object_handle &obj_to_bind) |
| Instructs the switch to bind itself to the given dynamic object. | |
Private Types | |
| typedef rc_port_traits< PORT > | port_traits |
| typedef rc_abstract_portal < port_type > | this_type |
| typedef rc_portal_b < if_type > | base_type |
Private Member Functions | |
| RC_STATIC_ASSERT_VALID_PORT (PORT) | |
Private Attributes | |
| bool | p_is_unused |
| flag to indicate if portal is declared as unused | |
typedef rc_port_traits<PORT> port_traits [private] |
Definition at line 346 of file rc_abstract_portal.h.
| typedef PORT port_type |
Reimplemented in rc_event_queue_portal, rc_fifo_in_portal, rc_fifo_out_portal, rc_mutex_portal, rc_portal, rc_portal< sc_out_resolved >, rc_in_resolved_portal, rc_inout_resolved_portal, rc_out_resolved_portal, rc_portal< sc_out_rv< W > >, rc_in_rv_portal, rc_inout_rv_portal, rc_out_rv_portal, rc_semaphore_portal, rc_portal< sc_out< T > >, rc_in_portal, rc_inout_portal, rc_out_portal, rc_portal< sc_in_rv< W > >, rc_portal< sc_port< sc_mutex_if > >, rc_portal< sc_in_resolved >, rc_portal< sc_inout< T > >, rc_portal< sc_in< T > >, rc_portal< sc_inout_rv< W > >, rc_portal< sc_inout_resolved >, rc_portal< sc_fifo_in< T > >, rc_portal< sc_fifo_out< T > >, rc_portal< sc_port< sc_event_queue_if > >, and rc_portal< sc_port< sc_semaphore_if > >.
Definition at line 349 of file rc_abstract_portal.h.
| typedef port_traits::if_type if_type |
Reimplemented from rc_portal_b.
Reimplemented in rc_event_queue_portal, rc_fifo_in_portal, rc_fifo_out_portal, rc_mutex_portal, rc_portal, rc_portal< sc_out_resolved >, rc_in_resolved_portal, rc_inout_resolved_portal, rc_out_resolved_portal, rc_portal< sc_out_rv< W > >, rc_in_rv_portal, rc_inout_rv_portal, rc_out_rv_portal, rc_semaphore_portal, rc_portal< sc_out< T > >, rc_in_portal, rc_inout_portal, rc_out_portal, rc_portal< sc_in_rv< W > >, rc_portal< sc_port< sc_mutex_if > >, rc_portal< sc_in_resolved >, rc_portal< sc_inout< T > >, rc_portal< sc_in< T > >, rc_portal< sc_inout_rv< W > >, rc_portal< sc_inout_resolved >, rc_portal< sc_fifo_in< T > >, rc_portal< sc_fifo_out< T > >, rc_portal< sc_port< sc_event_queue_if > >, and rc_portal< sc_port< sc_semaphore_if > >.
Definition at line 350 of file rc_abstract_portal.h.
| typedef rc_accessor<if_type> accessor_type |
Reimplemented from rc_portal_b.
Reimplemented in rc_event_queue_portal, rc_fifo_in_portal, rc_fifo_out_portal, rc_mutex_portal, rc_portal, rc_portal< sc_out_resolved >, rc_in_resolved_portal, rc_inout_resolved_portal, rc_out_resolved_portal, rc_portal< sc_out_rv< W > >, rc_in_rv_portal, rc_inout_rv_portal, rc_out_rv_portal, rc_semaphore_portal, rc_portal< sc_out< T > >, rc_in_portal, rc_inout_portal, rc_out_portal, rc_portal< sc_in_rv< W > >, rc_portal< sc_port< sc_mutex_if > >, rc_portal< sc_in_resolved >, rc_portal< sc_inout< T > >, rc_portal< sc_in< T > >, rc_portal< sc_inout_rv< W > >, rc_portal< sc_inout_resolved >, rc_portal< sc_fifo_in< T > >, rc_portal< sc_fifo_out< T > >, rc_portal< sc_port< sc_event_queue_if > >, and rc_portal< sc_port< sc_semaphore_if > >.
Definition at line 351 of file rc_abstract_portal.h.
typedef rc_abstract_portal<port_type> this_type [private] |
typedef rc_portal_b<if_type> base_type [private] |
Reimplemented from rc_portal_b.
Reimplemented in rc_event_queue_portal, rc_fifo_in_portal, rc_fifo_out_portal, rc_mutex_portal, rc_portal, rc_portal< sc_out_resolved >, rc_in_resolved_portal, rc_inout_resolved_portal, rc_out_resolved_portal, rc_portal< sc_out_rv< W > >, rc_in_rv_portal, rc_inout_rv_portal, rc_out_rv_portal, rc_semaphore_portal, rc_portal< sc_out< T > >, rc_in_portal, rc_inout_portal, rc_out_portal, rc_portal< sc_in_rv< W > >, rc_portal< sc_port< sc_mutex_if > >, rc_portal< sc_in_resolved >, rc_portal< sc_inout< T > >, rc_portal< sc_in< T > >, rc_portal< sc_inout_rv< W > >, rc_portal< sc_inout_resolved >, rc_portal< sc_fifo_in< T > >, rc_portal< sc_fifo_out< T > >, rc_portal< sc_port< sc_event_queue_if > >, and rc_portal< sc_port< sc_semaphore_if > >.
Definition at line 355 of file rc_abstract_portal.h.
| rc_abstract_portal | ( | ) | [inline, protected] |
| rc_abstract_portal | ( | const sc_module_name & | module_name | ) | [inline, explicit, protected] |
Definition at line 544 of file rc_abstract_portal.h.
| RC_STATIC_ASSERT_VALID_PORT | ( | PORT | ) | [private] |
| void bind_static | ( | port_type & | port_ | ) | [inline] |
| void bind_static | ( | if_type & | channel_ | ) | [inline] |
| void bind_dynamic | ( | port_type & | port_ | ) | [inline] |
create a new accessor and bind it to the given dynamic port
Definition at line 553 of file rc_abstract_portal.h.
Referenced by rc_abstract_portal::bind_dynamic_object(), and rc_abstract_portal< sc_port< sc_semaphore_if > >::dynamic_port().
| void dynamic_port | ( | port_type & | port_ | ) | [inline] |
allows dynamic port binding (alias for bind_dynamic())
Definition at line 376 of file rc_abstract_portal.h.
| void unused | ( | ) | [inline, virtual] |
bind static_port to rc_fallback_interface<IF>
Implements rc_portal_b.
Definition at line 568 of file rc_abstract_portal.h.
| virtual bool is_unused | ( | ) | const [inline, virtual] |
| port_type& get_static_port | ( | ) | [inline] |
| void bind_static_object | ( | const rc_object_handle & | obj_to_bind | ) | [inline, protected, virtual] |
Instructs the switch to bind itself to the given static object.
Implements rc_switch.
Definition at line 582 of file rc_abstract_portal.h.
| void bind_dynamic_object | ( | const rc_object_handle & | obj_to_bind | ) | [inline, protected, virtual] |
Instructs the switch to bind itself to the given dynamic object.
Implements rc_switch.
Definition at line 606 of file rc_abstract_portal.h.
the port for the static interface
Definition at line 397 of file rc_abstract_portal.h.
Referenced by rc_abstract_portal< sc_port< sc_semaphore_if > >::bind_static(), rc_abstract_portal::bind_static_object(), rc_abstract_portal< sc_port< sc_semaphore_if > >::get_static_port(), rc_abstract_portal::rc_abstract_portal(), and rc_abstract_portal::unused().
bool p_is_unused [private] |
flag to indicate if portal is declared as unused
Definition at line 402 of file rc_abstract_portal.h.
Referenced by rc_abstract_portal< sc_port< sc_semaphore_if > >::is_unused(), and rc_abstract_portal::unused().
